VMware vSphere 6 Update Manager Database

VMware vSphere 6 Update Manager Database

Although the VMware vSphere 6 Update Manager installation provides the option to install and configure an embedded version of SQL Express 2012 server,  we will instead opt to utilize the SQL server utilized for vCenter, create a new database for Update Manager and create a system DSN entry.  These steps are similar if we wanted to utilize an external SQL database for Update Manager.

[contentblock id=2 img=gcb.png]

Database Creation

Launch Microsoft SQL Server Management Studio, right-click Databases and select New Database….

vCenter_6_Update_Manager_Installation_Prereq_DB _01

Enter a name for the database and click OK.  In this case we entered vSphere_Update_Manager but you can pick your own name.

vCenter_6_Update_Manager_Installation_Prereq_DB _02

The database is created.

vCenter_6_Update_Manager_Installation_Prereq_DB _03

System DSN Creation

Launch the ODBC Administrator.  Navigate to the System DSN tab and click Add.

vCenter_6_Update_Manager_Installation_Prereq_01

Select SQL Server Native Client and click Finish.  The options for SQL Server client may differ, depending on the version of SQL utilized.

vCenter_6_Update_Manager_Installation_Prereq_02

Enter a name, description and the server name.  This is the name of the DSN and will be utilized during the vSphere 6 Update Manager installation as described in this article.  As you can see from the Server name, we have utilized the SQL Express instance of vCenter from a 5.x installation but you may opt to utilize a different SQL server.  Click Next.

vCenter_6_Update_Manager_Installation_Prereq_03

Check the option “Change the default database to:” and select the database created in the early part of this article.  Click Next.

vCenter_6_Update_Manager_Installation_Prereq_DB _04

Click Finish.

vCenter_6_Update_Manager_Installation_Prereq_06

Click Test Data Source.

vCenter_6_Update_Manager_Installation_Prereq_07

The result should be successful.  Click OK.

vCenter_6_Update_Manager_Installation_Prereq_08

You may now proceed to this article.

References:

VMware vSphere 6 Update Manager Installation
